Kona Dew HD

Hub drive electric bike seeking ideal rider! Hi! My name is Dew HD! I’m affordable, super fun, stylish, extremely practical, easy-riding, helpful, full of light. You: loathe climbing hills, love (pedal) assistance, enjoy smiling, like going fast, don’t love working that hard if you don’t have to, need a companion to carry your groceries/beer/kids/dog/gear to and from wherever. Let’s fall in love!

---

Technical Specifications

Component	Specification
Frame Material	Kona 6061 Aluminum Butted
Fork	Kona Project Two Aluminum
Rims	WTB SX19
Front Hub	Shimano 100x9mm
Rear Hub	SR Suntour HD 20MPH
Spokes	Stainless Black 14g/13g
Front Tire	WTB Horizon Comp 650x47c
Rear Tire	WTB Horizon Comp 650x47c
Crankset	Suntour
Chainring	38t
Drive Unit	SR Suntour HD 20MPH
Battery	Phylion 418Wh
Rear Derailleur	Shimano TX
Cassette	Shimano Altus 11-32t 8spd
Chain	KMC Z8.3
Shifters	Shimano Altus
Brakes	Tektro HDM275 Hydraulic
Front Brake Rotor	Tektro TR180 180mm
Rear Brake Rotor	Tektro TR180 180mm
Handlebars	Kona ALuminum Riser
Grips	Kona Key Grip Slip on
Stem	Kona Control
Headset	Feimin FP-H863
Seatpost	Kona Commuter 27.2mm
Seat Clamp	Kona Clamp
Saddle	Kona Commuter

All specifications subject to change without notice

---

Sizing Guide

Rider Height	Suggested Frame Size
5'11" - 6'2"]	X-Large

Sizing

Available in multiple sizes to fit a wide range of riders.
Contact us if you need help choosing the correct size.

---
